Product Detail
Sealer
Detail






Features:


1、This series is based on stand-alone models, up and down, "a" font automatic sealing and packaging operations

2、Drive design, mining on both sides of the drive to send boxes with tape packing operation

3、Applicable carton specifications, manual adjustment (1 to 2 minutes) can be completed

4、Package items, all cartons are available in this series

5、Economical, labor-saving, beautiful, lightweight models

6、Mechanical performance of precision and durability, stable operation and long life

7、Pledges to ensure artificial than beautiful, fast, high efficiency


Specification Table:


model

PFC-558 Standard single model(unit:MM

Suitable carton

400780Lx280340Wx150290H

Table height

Min700MM、maximum800MMHWith brake wheel

Sealing speed

per hour480Above box

Mechanical Dimensions

2050L×840W×1450H

using electric

380V360HZ

Use gas source

5kgf/c㎡-40ni/min

Apply tape

60mmW-2.5Inch*1000code/L.-OPP

Mechanical weight

net weight180Kg

Mechanical weight

Gross weight260kgs(Including the total weight of wooden box)
